Garrison Flood Control - Guppy Water Filled Flood Tube - 24" Diameter
Details
Garrison Flood Control - Guppy Water Filled Flood Tube - 24" Diameter
The Guppy™ water filled flood tube is an easy to fill and deploy water barrier that will redirect water and provide protection for homes, municipal buildings, infrastructure and equipment. Each water filled flood control tube becomes heavy with water when filled, creating a durable berm that protects against rising floodwaters.
Choose the right Guppy size, depending on your specific water diversion requirements and combine tubes sections as needed to create longer protective barriers with a protection height of 24 inches and lengths of 50ft, or 100ft.
Each Guppy water filled tube is reusable. Once a flood event is over, it can simply be drained of water, rolled up and put back in storage for future use. The Guppy™ water filled flood control tube is manufactured using high quality composite PVC mesh material that is UV treated, anti-static, waterproof, and chemical and oil resistant. Each tube has incredible tear and tension strength.
Features:
- Water Filled Flood Control Tube - Easy to Use, Deploy and Store - just place and fill with water
- Redirect Damaging Flood Water - Block entryways, doorways, garages, and more
- 50 feet long by 24 inches high - 22 inches of protection height - holds 1,175.04 gallons of non-potable water
- 100 feet long by 24 inches high - 22 inches of protection height - holds 2,350.08 gallons of non-potable water
Specifications
Tube Construction:
The Guppy™ water filled flood control tube is manufactured using high quality composite PVC mesh material that is UV treated, anti-static, waterproof, and chemical and oil resistant. Each tube has incredible tear and tension strength.
- Material: Composite PVC mesh
- Material Thickness: 0.9mm +/- 0.02%
- Whole thermal bonding molding construction
- Fire Resistance: EN13501-B1
- Usage Temperature: -32F to 158 F (RV anti-freeze is recommended for below freezing temperatures. Tubes should be no more than 3/4 full if freezing is expected)
- We recommend damming to within 2” of the top height of the barrier, such that each 6” tall barrier is suitable to protect against floods of roughly 10”
Empty Guppy Tube Weights:
G24-50:
- 50ft x 24” Guppy Tube = 53lbs
- Size Folded 20”L x 7”H x 26”W, or so
G24-100:
- 100ft x 24” Guppy Tube = 105lbs
- Size Folded 20”L x 13”H x 26”W, or so
Other Specifications:
- Material: Composite PVC mesh
- Material Weight: 21.5 oz. / 610 GSM / 1000D 20*20
- Construction: Whole thermal bonding molding construction
- Fire Resistance: EN13501-B1
- Usage Temperature: -32F to 158 F (RV anti-freeze is recommended for below freezing temperatures. Tubes should be no more than 3/4 full if freezing is expected).
