Tohatsu VF53AS 4-Stroke Portable Fire Pump

(0) No Reviews yet


Tohatsu VF53AS 4-Stroke Portable Fire Pump

This portable fire pump boasts a 4-Stroke engine with a hassle free "Auto-Priming" system.

Quick Priming

Quick priming is provided by a simple operating rotary vane vaccum pump. The pump primes 3 meters in only 3 seconds.

Engine Overheat Protection Sensor

Engine overheat protection device is provided to safeguard against cooling water loss, and to protect engine in the operation with discharge valve closed. This device automatically shuts off when engine temperature reaches 176 F.

Auto Priming System

Rotary vane vaccum pump is automatically activated after engine starts, and cut off once priming is completed.

  • Type: 4-Stroke
  • Cylinders: 3
  • Cooling System: Suction Water Cooled
  • Bore x Stroke: 61 x 60 mm (2.4 x 2.36 inch)
  • Piston Displacement: 526 mL
  • Output: 22.1 kW
  • Fuel Type: Unleaded Gasoline (Min. 87 Octane)
  • Fuel Tank Capacity: 10 liters (2.64 gal)
  • Fuel Consumption: 9.5 Liter / Hr. (2.51 gal/ Hr.)
  • Fuel System: EFI
  • Oil Tank Capacity: 2 Liter (.53 gal)

  • Starting: Electric & Manual
  • Suction System: 4 Blade Rotary-vane vaccum pump (oilless-type)
  • Priming System: Auto Priming

  • Pump Type: Single Suction, Single stage centrifugal pump
  • Suction Thread & Dia.: JIS 3" (75mm)
  • Discharge Thread & Dia.: JIS 2.5" (65mm)
  • Discharge Number: Twin
  • Discharge Valve: Ball or Flat
  • Weight: 101 kg (222.66 lbs.)
  • Dimensions: 27 x 31 x 29
